神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (01-048) - GUARD INSTAL (COUNTERWEIGHT) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
289 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY21C00007F3 | [1] | GUARD ASSY. | KOB |
| 3. | HS18C10025G1 | [4] | SCREW | KOB Superseded by part number: ZS18C10025 |
| 4. | YT21C01172P1 | [4] | LOCK WASHER | KOB |
| 5. | HY25X11024G1 | [4] | WASHER | KOB |
| 6. | YT21C01187P1 | [4] | WASHER | KOB Superseded by part number: YT21C01187P2 |
| 7. | ZM32C12030 | [2] | BOLT | KOBM12x1.75x30mm (Incls. Washer & Lockwasher) |
| 9. | YY21C01060P1 | [1] | GUARD | KOB |
| 10. | YY21C01045F3 | [1] | GUARD ASSY. | KOB |
| 10-1. | YY21C01046P1006 | [1] | STAY | KOBNo ref# |
| 10-2. | YT21C01090F2 | [1] | LOCK | KOBASSY |
| 10-2A. | YR22C01025P1 | [1] | LOCK | KOB, Serial Range: YH02-01301-YH02-02096 Superseded by part number: YR22C01025P2 |
| 10-2A. | YR22C01025P2 | [1] | LOCK | KOB, Start Serial: YH03-02097- |
| 10-2C. | YT21C01136P1 | [1] | PLATE | KOB |
| 10-4. | YY21C01272P1 | [1] | GUARD | KOB |
| 10-4C. | YX21C01056P1 | [2] | HINGE | KOB |
| 10-6. | YT21C01354P1 | [1] | STAY | KOB |
| 10-7. | ZW16X08000 | [1] | WASHER,8mm ID x 17mm OD x 1.6mm Thk | KOBID 08 x OD 17 x Th 1.6mm |
| 10-8. | 2419R9D2 | [1] | COTTER PIN | KOBOD 08mm x 27.7mm Long |
| 10-9. | YR21C01123P1 | [1] | COLLAR | KOB |
