纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-043-00[01]) - BOX - OPERATORS COMPARTMENT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
941 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 11. | KHN3590 | [1] | BOX | SUM |
| 12. | KHN2303 | [1] | SPECIAL NUT | SUM |
| 13. | KHN2304 | [2] | SEAL | SUM |
| 14. | KHN2305 | [1] | SEAL | SUM |
| 15. | KHN2306 | [1] | SEAL | SUM |
| 16. | KHN2307 | [1] | SEAL | SUM |
| 18. | KHN2309 | [7] | BOLT,Spcl | SUM |
| 24. | KHN2238 | [1] | BRACKET | SUM |
| 25. | KHR2740 | [2] | SELF-TAP SCREW | SUM |
| 26. | KHN2317 | [2] | WASHER | SUM |
| 27. | KHN2322 | [1] | SEAL | SUM |
| 28. | KHN3598 | [1] | COVER | SUM |
| 29. | KHN2321 | [2] | HINGE | SUM |
| 30. | KHR2731 | [12] | SELF-TAP SCREW | SUM |
| 31. | KHN2320 | [2] | CATCH | SUM |
| 32. | KHN2333 | [2] | MAGNET | SUM |
| 33. | KHN2334 | [2] | PLATE | SUM |
| 34. | 152031A1 | [4] | SCREW | SUM |
| 35. | KHR2729 | [4] | SELF-TAP SCREW | SUM |
| 36. | KHN2323 | [1] | RUBBER SEAL | SUM |
| 37. | KHN2324 | [2] | SEAL | SUM |
