纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-079-02[01]) - CAB GUARD - ANTI-VANDALISM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
771 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KHN3414 | [1] | COVER | SUM |
| 2. | NSS | [2] | NOT SERVICED SEPARATELY | CONHinge |
| 3. | KHN2870 | [1] | COVER | SUM |
| 4. | 162880A1 | [4] | BOLT | SUM |
| 5. | 159657A1 | [2] | BOLT,High Strength, M10 | SUMM10 x 20; 10.9 |
| 6. | 167472A1 | [6] | BOLT,High Strength, M10 x 20mm, Cl 10.9 | SUM |
| 7. | 150409A1 | [8] | WASHER | SUM10,5 x 21 x 3,2 mm |
| 8. | 150854A1 | [2] | FASTENER | SUM |
| 9. | 150856A1 | [2] | STOP LOCK | SUM |
| 10. | 627-8020 | [8] | BOLT,Hex, M8 x 1.25 x 20mm, Cl 10.9, Full Thd | CAS Superseded by part number: 43233 |
| 10A. | 896-15008 | [8] | WASHER,9mm ID x 21mm OD x 2.5mm Thk | CAS9 x 21 x 2,5 mm Superseded by part number: 87015284 |
| 12. | 150469A1 | [4] | FLANGE NUT | SUM |
| 13. | 151756A1 | [2] | PLATE WASHER | SUM |
| 14. | 161804A1 | [4] | RUBBER BLOCK | SUM |
