纽荷兰零件查询(E805) - CRAWLER EXCAVATOR (1/05-) (09-081-00[01]) - AIR CONDITIONING - UPPERSTRUCTURE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
571 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 27. | 167528A1 | [1] | RECEIVER-DRIER | SUM Superseded by part number: KHR3751 |
| 28. | 159635A1 | [1] | SUPPORT | SUM |
| 29. | 162043A1 | [2] | BOLT,Spcl, M6 | SUM |
| 30. | 167320A1 | [2] | BOLT,Spcl, M8 x 20mm | SUM |
| 31. | 159906A1 | [2] | BOLT,Sems, Hex, M6 x 20mm, Spcl | SUM |
| 39. | KHR3297 | [1] | HOSE | SUM |
| 40. | 169054A1 | [2] | O-RING | CAS |
| 41. | KHR3298 | [1] | HOSE | SUM |
| 45. | 168367A1 | [1] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHH12760 |
| 46. | 151563A1 | [1] | PLASTIC-RUBBER TUBE | SUM3800 mm (149-5/8 in) Superseded by part number: KHH12760 |
| 47. | 159037A1 | [3] | MOUNTING CLIP | SUM |
| 48. | 150469A1 | [6] | FLANGE NUT | SUM |
| 49. | KHR2582 | [3] | CLAMP | SUM |
| 50. | 627-10025 | [3] | BOLT,Hex, M10 x 1.5 x 25mm, Cl 10.9, Full Thd | CAS Superseded by part number: 11106231 |
| 51. | 140028 | [3] | WASHER,10.2mm ID x 18.1mm OD x 2.2mm Thk | NH |
| 52. | 895-11010 | [3] | WASHER,11mm ID x 20mm OD x 2mm Thk | CAS Superseded by part number: 14496621 |
| 53. | 150860A1 | [14] | COLLAR | SUM |
| 54. | 145N006S008R | [14] | SCREW,Pan Hd, M6 x 8mm, Cl 10.9 | SUM |
| 55. | 150071A1 | [1] | MOUNTING CLIP | SUM |
| 56. | 150496A1 | [1] | MOUNTING CLIP | SUM |
| 57. | 157520A1 | [2] | HOSE,13 mm ID x 6500.00 mm | SUM |
| 58. | 157925A1 | [2] | PLASTIC-RUBBER TUBE | SUM Superseded by part number: KHR21060 |
| 65. | KTR0531 | [1] | FOAM INSULATION | SUM |
| 66. | KHH0358 | [2] | RETAINER | SUM |
| 67. | 627-8040 | [2] | BOLT,Hex, M8 x 1.25 x 40mm, Cl 10.9, Full Thd | SUM |
| 68. | 895-11008 | [2] | WASHER,M8 x 16 x 1.6 | CAS9 x 17 x 1,6 mm Superseded by part number: 86624184 |
