神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (10-006) - CAMSHAFT AND VALVE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
142 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONCAMSHAFT AND VALVE |
| 1. | VI8973595871 | [1] | CAMSHAFT | KOBCAMSHAFT |
| 4. | VI1125511650 | [4] | VALVE | KOBVALVE, INL |
| 5. | VI1125521110 | [4] | VALVE | KOBVALVE, EXH |
| 7. | VI5090002360 | [1] | BOLT | KOBBOLT, CM/SHF GEAR |
| 9. | VI1125220162 | [1] | GEAR, CM/SHF (Z=50) | |
| 10. | VI9116810150 | [1] | THRUST PLATE | KOBPLATE,THRUST |
| 11. | VI0500408250 | [2] | BOLT | KOBBOLT,THRUST PLATE TO C/BL Superseded by part number: VI0505408250 |
| 12. | VI9080107200 | [1] | KEY | KOBKEY, CAM GEAR SET |
| 45. | VI9098518503 | [1] | WASHER | KOBWASHER, GEAR CAM |
| 53. | VI8972222450 | [1] | SHAFT | KOBSHAFT, ROCKER ARM |
| 55. | VI9126260050 | [2] | PLUG | KOBPLUG, ROCKER SHAFT END |
| 58. | VI5126280120 | [1] | BRACKET | KOBBRACKET, ROCKER SHAFT, FRT |
| 59. | VI5096230600 | [1] | O-RING | KOBGASKET, ROCKER SHAFT |
| 65. | VI5125650060 | [16] | COLLAR | KOBCOLLAR, SPLIT |
| 69. | VI1125610991 | [8] | SPRING | KOBSPRING, VLV, OUTER |
| 71(A). | VI8941145790 | [8] | SEAT | KOBSEAT, SPR (UPPER) |
| 71(B). | VI5125630010 | [8] | SEAT | KOBSEAT, SPR (LOWER) |
| 72. | VI8971201670 | [8] | SEAL | KOBSEAL, VLV GUIDE |
| 76. | VI9098514300 | [3] | WASHER | KOBWASHER, PL, BRKT |
| 78. | VI1126112490 | [8] | ROCKER ARM | KOBARM, ROCKER Superseded by part number: 72109904 |
| 81. | VI9126160420 | [8] | ADJUSTMENT SCREW | KOBSCREW, ADJ, ROCKER ARM |
| 83. | VI9091115080 | [8] | NUT | KOBNUT,ADJ SCREW, LK Superseded by part number: VI0911115080 |
| 84. | VI9126281050 | [4] | BRACKET | KOBBRACKET,ROCKER SHAFT, INTER |
| 85. | VI1090005670 | [6] | BOLT | KOBBOLT,BRKT |
| 86. | VI9098514300 | [6] | WASHER | KOBWASHER, ROCKER ARM FIX |
| 88. | VI1125750360 | [8] | ROD | KOBROD, PUSH Superseded by part number: 289165A1 |
| 89. | VI5125710033 | [8] | TAPPET | KOBTAPPET, VALVE |
| 93. | VI1094001160 | [3] | NUT | KOBNUT, BRKT |
| 95. | VI1095803350 | [3] | SPRING | KOBSPRING, ROCKER SHAFT |
| 101. | VI5090300381 | [2] | BOLT | KOBBOLT, THRUST COLLAR |
| 107. | VI9125310300 | [1] | SHAFT | KOBSHAFT, IDLE GEAR |
| 111. | VI5125350011 | [1] | COLLAR | KOBCOLLAR, THRUST, IDLER GEAR |
| 112. | VI8941339373 | [1] | GEAR | KOBGEAR, IDLER (Z=51) |
| 196. | VI9091800190 | [1] | SNAP RING | KOBRING, SNAP |
