神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (10-008) - TIMING GEAR CASE AND FLYWHEEL HOUSING Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
130 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONTIMING GEAR CASE AND FLYWHEEL HOUSING |
| 1(C). | VI8944509752 | [1] | CASE | KOBTIMING GEAR |
| 2(A). | VI8971333292 | [1] | MOTOR HOUSING | KOBFLYWHEEL Superseded by part number: 72961672 |
| 36. | VI0280808220 | [4] | BOLT, GEAR CASE (M8X22 FLANGE) | |
| 36. | VI0280808450 | [2] | BOLT | KOBBOLT, GEAR CASE (M8X45 FLANGE) Superseded by part number: VI0280508450 |
| 42. | VI9112290581 | [1] | DOWEL | KOBGEAR CASE COVER |
| 49(C). | VI8972333010 | [1] | GASKET | KOBGEAR CASE TO COVER |
| 54(C). | VI8971298300 | [1] | COVER | KOBGEAR CASE |
| 56. | VI8943706710 | [1] | GASKET | KOBGEAR CASE TO COVER Superseded by part number: VI8943706711 |
| 57. | VI5113210090 | [2] | COVER | KOBTIMING CHECK HOLE |
| 58. | VI0280806120 | [4] | BOLT | KOBCHECK HOLE COVER (M6X12 FLANGE) |
| 62(B). | VI0280808220 | [8] | BOLT; COVER (M8X22 FLANGE) | |
| 62(B). | VI0280808800 | [1] | BOLT | KOBCOVER (M8X80 FLANGE) Superseded by part number: 87597729 |
| 62(B). | VI0280810500 | [3] | BOLT, COVER (M10X50 FLANGE) | |
| 62(B). | VI1090440711 | [2] | BOLT | KOBCOVER (M8X55 FLANGE) |
| 103(C). | VI1096254380 | [1] | OIL SEAL | KOBCR/SHF, FRT |
| 115(A). | VI1815105130 | [1] | SENSOR | KOBREVOLUTION, ENG SPD |
| 166(B). | VI8943706640 | [1] | GASKET | KOBRET TO C/BL Superseded by part number: VI8943706641 |
| 172(B). | VI8970795200 | [1] | RETAINER | KOBCR/SHF |
| 175. | VI8970728231 | [1] | SEAL | KOBOIL, CR/SHF, RR |
| 185. | VI0286808250 | [7] | BOLT | KOBRET TO C/BL (M8X25 FLANGE) |
| 211(B). | VI0280806100 | [3] | BOLT; HSG (M6X10 FLANGE) | |
| 224. | VI9944112350 | [2] | STUD | KOBSTARTER (M12X35 L=53) |
| 248. | VI8970428010 | [1] | COVER | KOBDUST, FLYWHEEL HSG RET |
| 251. | VI9113491341 | [1] | COVER | KOBTIMING, CHECK HOLE |
