神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (10-010) - INLET MAINIFOLD Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
601 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONINLET MANIFOLD |
| 1(C). | VI8972488530 | [1] | MANIFOLD | KOBINL |
| 7(B). | VI8972357881 | [2] | MANIFOLD GASKET | KOBINL MANIF TO HD Superseded by part number: 87448397 |
| 8. | VI8943706760 | [1] | GASKET | KOBINL DUCT |
| 20. | VI0911501080 | [4] | NUT | KOBINL MANIF Superseded by part number: VI0911802080 |
| 144. | VI0280808250 | [4] | BRACKET | KOBBOLT, FIX (M8X25 FLANGE) Superseded by part number: VI0280508250 |
