神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (10-023) - OIL PUMP AND OIL STRAINER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
643 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONOIL PUMP AND OIL STRAINER |
| 1(A). | VI8971281100 | [1] | PUMP | KOBASM, OIL |
| 2. | VI5131650040 | [1] | SPRING SEAT | KOB |
| 3. | VI9081140300 | [1] | PIN, SPLIT | |
| 5. | VI5095800980 | [1] | SPRING | KOBCOIL |
| 8. | VI8941635950 | [1] | GEAR | KOBDRIVEN, OIL PUMP |
| 19. | VI5878120080 | [1] | GEAR SET | KOBOIL PUMP |
| 21. | VI9095612230 | [1] | GASKET | KOBOIL PUMP |
| 29. | VI0280810250 | [2] | BOLT, OIL PUMP (M10X25 FLANGE) | |
| 31(A). | VI5131130380 | [1] | COVER | KOBOIL PUMP |
| 32. | VI1131280180 | [1] | PINION | KOBOIL PUMP DRIVING |
| 34. | VI8941635940 | [1] | GEAR | KOBSHAFT, OIL PUMP |
| 35. | VI8941635970 | [1] | COVER | KOBOIL PUMP |
| 40. | VI1131230160 | [1] | COUPLING | KOBPINION TO SHAFT |
| 41. | VI5098430030 | [1] | BALL | KOBOIL RELIEF VLV |
| 43. | VI5090002140 | [4] | BOLT | KOBCASE |
| 46. | VI9131430100 | [1] | FILTER STRAINER | KOBGAUZE, OIL |
| 67. | VI9091505080 | [4] | WASHER | KOBLK, OIL PUMP Superseded by part number: VI0915105080 |
| 76. | VI8941671180 | [1] | PIPE | KOBASM, OIL |
