神钢零件查询(ED150-1E) - BLADE RUNNER EXCAVATOR/DOZER ASN YL05-00555 (11/03-12/04) (10-024) - OIL AND VACCUM PIPING; ENGINE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
358 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | NSS | [1] | NOT SOLD SEPARAT | CONOIL AND VACUUM PIPING; ENGINE |
| 1. | VI8971242340 | [1] | PIPE | KOBOIL, INJ PUMP TO C/BL |
| 2(B). | VI1096750810 | [1] | BOLT, EYE, OIL PIPE (M12X24) | |
| 3. | VI9095714100 | [2] | SEAL | KOBEYE BOLT, OIL PIPE |
| 3. | VI1096300840 | [2] | GASKET, EYE BOLT, OIL PIPE | |
| 26(B). | VI8941310603 | [1] | PIPE, OIL, PUMP TO C/BL | |
| 28. | VI9099211880 | [2] | O-RING | KOBGASKET, OIL PIPE |
| 37(C). | VI8972274660 | [1] | TUBE | KOBPIPE, OIL, FILTER TO COOLER |
| 40(B). | VI0280808300 | [2] | BOLT | KOBOIL PIPE (M8X30 FLANGE) Superseded by part number: VI0280508300 |
| 40(B). | VI0280808350 | [1] | BOLT, OIL PIPE (M8X35 FLANGE) | |
| 40(A). | VI0501408450 | [4] | BOLT | KOBOIL PIPE (M8X45 W/LK & PL WASHER) Superseded by part number: VI0500408450 |
| 40(B). | VI0280808200 | [1] | BOLT | KOBOIL PIPE (M8X20 FLANGE) Superseded by part number: VI0280508200 |
| 44. | VI0280808120 | [1] | BOLT, CLIP, OIL PIPE (M8X12 FLANGE) | |
| 44. | VI0286810300 | [1] | BOLT | KOBCLIP, OIL PIPE (Ml0X30 W/LK WASHER) |
| 47. | VI1096234620 | [2] | PACKING | KOBGASKET, OIL PIPE |
| 63(B). | VI8972221201 | [1] | PIPE | KOBOIL, TURBOCHARGER FEED |
| 116. | VI9095720100 | [2] | SEAL | KOBCAP NUT, OIL PIPE |
| 142. | VI9098440220 | [1] | NUT | KOBCAP, OIL PIPE, INJ PUMP TO C/BL |
| 232. | VI5123790010 | [1] | BRACKET | KOBSPACER, OIL PIPE CLIP |
