纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-002-00[01]) - AIR FILTRATION New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
537 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KWH0003 | [1] | FILTER ASSY | SUM |
| 2. | KWH0029 | [1] | AIR CLEANER | SUM Superseded by part number: 84217251 |
| 3. | KWH0050 | [1] | AIR FILTER | SUM |
| 4. | KWH0051 | [1] | FILTER COVER | SUM |
| 5. | KWH0052 | [1] | FILTER COVER | SUM |
| 6. | KWH0053 | [1] | VALVE SECTION | SUM |
| 7. | KWH0034 | [1] | BAND | SUM |
| 8. | 166347A1 | [4] | BOLT,Sems, M10 x 30mm | SUMM10 x 30 |
| 9. | 829-1410 | [2] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
| 10. | 150042A1 | [1] | SENSOR | SUM |
| 11. | 165818A1 | [1] | ELBOW | SUM |
| 12. | KWH0015 | [1] | AIR FLEXIBLE | SUM Superseded by part number: KWH10280 |
| 13. | KSJ2139 | [1] | FIXING STRIP | SUM |
| 14. | 158840A1 | [1] | BAND,133mm - 158mm | SUM |
| 15. | KUH10160 | [1] | AIR DUCT | SUM |
| 16. | 166352A1 | [2] | BOLT | SUMM12 x 30 |
| 17. | KWH0014 | [1] | AIR FLEXIBLE | SUM Superseded by part number: KWH10270 |
| 19. | 150855A1 | [1] | HOSE CLAMP,127mm - 146mm | SUM |
