纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-004-00[01]) - ENGINE WATER CIRCUIT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
478 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KUH10040 | [1] | RADIATOR | SUM Superseded by part number: LW005880, LG005910, LA011260, LS004220, LA012760, KUH10470, LH004680 |
| 2. | KWH0028 | [2] | AIR FLEXIBLE | SUM |
| 3. | KHH0412 | [4] | COLLAR | SUM |
| 4. | KWH0011 | [1] | AIR CHANNEL | SUM |
| 5. | KUH10060 | [1] | AIR DUCT | SUM |
| 6. | KUH10220 | [4] | SUPPORT | SUM |
| 7. | 152718A1 | [12] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 8. | 157781A1 | [1] | LARGE HOSE | SUMHOSE,LARGE 1500 mm Superseded by part number: 161495A1 |
| 9. | 150402A1 | [1] | TUBE,13 mm ID, 17.5 mm OD, 1300 mm Length | SUM1300 mm Superseded by part number: |
| 10. | 165951A1 | [1] | CLAMP | SUM |
| 11. | KUH10180 | [2] | SEAL | SUM |
| 12. | KWH0059 | [1] | SUPPORT | SUM |
| 13. | 166345A1 | [4] | BOLT | SUMM8 x 16 Superseded by part number: 105R008Y016R |
| 14. | KWH0054 | [1] | SEAL | SUM |
| 15. | KHH0358 | [5] | RETAINER | SUM |
| 16. | 827-8040 | [5] | BOLT,Hex, M8 x 1.25 x 40mm, Cl 10.9 | CAS Superseded by part number: 9780069 |
| 17. | 895-11008 | [5] | WASHER,M8 x 16 x 1.6 | CAS Superseded by part number: 86624184 |
| 18. | KWH0060 | [1] | SUPPORT | SUM |
| 20. | KWH0055 | [1] | SEAL | SUM |
| 24. | KUH10210 | [1] | SUPPORT | SUM |
| 26. | KUH10170 | [2] | SEAL | SUM |
| 27. | KUH10190 | [1] | SEAL | SUM |
| 28. | KUH10200 | [1] | SEAL | SUM Superseded by part number: KUH10201 |
| 29. | KWH10050 | [1] | RUBBER PAD | SUM |
| 33. | KWH10040 | [2] | SEAL | SUM |
| 59. | 102R020Y055R | [4] | BOLT | SUMM20 x 55 |
| 60. | 150817A1 | [4] | WASHER,21mm ID x 40mm OD x 4.5mm Thk | SUMW20 |
| 61. | 153209A1 | [1] | SHIM | SUM |
| 62. | 153208A1 | [1] | SHIM | SUM |
| 63. | KWH0063 | [1] | STAY | SUM |
| 64. | KWH0064 | [1] | STAY | SUM |
| 65. | 102R020Y040R | [4] | BOLT | SUMM20 x 40 |
| 67. | KWH0007 | [1] | LARGE HOSE | SUMHOSE,LARGE |
| 68. | KWH0008 | [1] | LARGE HOSE | SUMHOSE,LARGE |
| 69. | 165795A1 | [4] | COLLAR | SUM |
| 70. | KHH10850 | [2] | COOLANT EXPANSION RESERVOIR | SUM |
| 71. | KUH10240 | [1] | SUPPORT | SUM |
| 72. | 166352A1 | [4] | BOLT | SUMM12 x 30 |
| 73. | KUH10250 | [1] | BRACKET | SUM |
| 75. | KHH10370 | [1] | HYD CONNECTOR | SUM |
| 76. | KHH10340 | [2] | HOSE,50.00 mm | SUM |
| 78. | KHH0427 | [1] | HOSE | SUM2250 mm Superseded by part number: KHH12900 |
| 79. | 157814A1 | [1] | HOSE | SUM2000 mm |
| 80. | 165952A1 | [2] | MOUNTING CLIP | SUM |
| 81. | KWH0009 | [1] | AIR FLEXIBLE | SUM |
| 82. | 164968A1 | [1] | COLLAR | SUM |
| 83. | 164967A1 | [1] | COLLAR | SUM Superseded by part number: KHJ26110 |
| 84. | KWH10020 | [1] | AIR CHANNEL | SUM |
| 85. | KUH10230 | [1] | SUPPORT | SUM |
| 87. | KWH10030 | [1] | AIR FLEXIBLE | SUM |
| 88. | KHH0411 | [2] | COLLAR | SUM |
| 89. | KWH0010 | [1] | AIR FLEXIBLE | SUM |
| 91. | 161100A1 | [1] | MOUNTING CLIP | SUM Superseded by part number: L18331 |
| 92. | KHR2787 | [1] | CLAMP | SUM |
| 93. | 150496A1 | [1] | MOUNTING CLIP | SUM250 mm |
| 94. | KHP1407 | [1] | WARNING DECAL | SUM |
