纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-005-00[01]) - ENGINE WATER CIRCUIT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
871 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 34. | KWH0018 | [1] | ELECTRIC MOTOR | SUM |
| 35. | 627-12035 | [4] | BOLT,Hex, M12 x 1.75 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 626-12035 |
| 36. | 150811A1 | [4] | WASHER | SUMW12 Superseded by part number: 86625255 |
| 37. | 157580A1 | [2] | ELBOW,90º, 3/4" O-Ring x 3/4" | SUM |
| 38. | 154503A1 | [2] | O-RING | SUM |
| 39. | 159198A1 | [1] | ADAPTER | SUM |
| 41. | KRJ1231 | [1] | ADAPTER | SUM |
| 42. | 154475A1 | [1] | O-RING | SUM |
| 43. | KWH0042 | [1] | SUPPORT | SUM Superseded by part number: KWH10160 |
| 44. | KWH0043 | [2] | SUPPORT | SUM |
| 45. | 166348A1 | [8] | BOLT | SUMM16 x 45 |
| 46. | 627-16035 | [2] | BOLT,Hex, M16 x 2 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86529976 |
| 47. | 829-1416 | [2] | NUT,M16, Cl 10 | CAS Superseded by part number: 392530 |
| 48. | KWH0044 | [1] | HUB | SUM |
| 49. | KWH0045 | [1] | BOLT | SUMM10 x 45 |
| 50. | KWH0046 | [1] | WASHER | SUMW10 |
| 51. | 627-10035 | [4] | BOLT,Hex, M10 x 1.5 x 35mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86624978 |
| 52. | 150409A1 | [4] | WASHER | SUMW M10 |
| 53. | KWR10010 | [1] | WIRE HARNESS | SUM |
| 54. | KHR3748 | [1] | COLLAR | SUM |
| 55. | 167518A1 | [1] | BOLT | SUMM8 x 16 |
| 56. | 150860A1 | [5] | COLLAR | SUM |
| 57. | 840-168 | [5] | SCREW,Pan, M6 x 1 x 8mm, Cl 4.8 | CAS |
| 58. | 150496A1 | [5] | MOUNTING CLIP | SUM250 mm |
| 95. | KWH0019 | [1] | HYDRAULIC PUMP | SUM |
| 96. | 132R014Y035R | [2] | BOLT | SUMM14 x 1.5 x 35 |
| 97. | 150418A1 | [2] | WASHER | SUMM14 |
| 98. | KWH0047 | [1] | HYDRAULIC HOSE,19.00 mm ID x 1070.00 mm | SUM |
| 101. | KWH0048 | [1] | HYDRAULIC HOSE,19.00 mm ID x 710.00 mm | SUM |
| 102. | KAJ2917 | [1] | ADAPTER | SUM |
| 104. | KTJ1004 | [1] | HYDRAULIC HOSE,12.70 mm ID x 2450.00 mm | SUM2250 mm |
| 105. | 158065A1 | [1] | PLASTIC-RUBBER TUBE | SUM2000 mm Superseded by part number: KHR21050 |
| 106. | 152924A1 | [1] | PLUG | SUM |
| 108. | KHJ2023 | [1] | HOSE CLAMP | SUM |
| 109. | KHJ2025 | [1] | CLAMP | SUM |
| 110. | 166052A1 | [1] | BOLT | SUMM10 x 25 Superseded by part number: 11106231 |
| 111. | KHR2584 | [3] | CLAMP | SUM |
| 112. | KHJ1215 | [3] | BOLT,Spcl | SUMM8 x 25 |
