纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-011-01[01]) - CYLINDER HEAD New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
342 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87562027 | [1] | CYLINDER HEAD | ISU |
| 4. | 288548A1 | [24] | GUIDE | ISU |
| 5A. | 87384339 | [12] | SPRING LOCK | ISUExhaust |
| 5B. | 87384340 | [12] | VALVE SEAT | ISUInlet |
| 8A. | 289414A1 | [2] | CUP | ISUOD 12.3 Superseded by part number: 368335A1 |
| 8B. | 362152A1 | [2] | CUP | CASOD 32 |
| 8C. | 289076A1 | [10] | CUP | ISUOD 25 |
| 8D. | 288553A1 | [18] | PLUG | ISUOD 40 |
| 8E. | 353962A1 | [6] | PLUG | ISUOD 16 |
| 8F. | 359866A1 | [12] | CUP | CASOD 18 |
| 57. | 87384351 | [6] | NOZZLE HOLDER | ISU |
| 58A. | 288562A1 | [6] | GASKET | ISUBlack Superseded by part number: 72110172 |
| 58B. | 288563A1 | [6] | GASKET | ISURed Superseded by part number: 72110173 |
