纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-015-01[01]) - PISTONS AND CRANKSHAFT New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
445 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87384743 | [1] | CRANKSHAFT | ISU |
| 7. | 288923A1 | [1] | CRANKSHAFT BEARING | ISU |
| 12. | 87384744 | [1] | ENGINE FLYWHEEL | ISU |
| 18. | 87384745 | [1] | PULLEY | ISU |
| 20. | 419824A1 | [1] | DAMPER | ISU |
| 22. | 419825A1 | [8] | WASHER | ISUID 18 |
| 23. | 419826A1 | [1] | WASHER | ISU |
| 24. | 419827A1 | [8] | BOLT | ISUM12 x 30 |
| 28. | 419829A1 | [1] | GEAR | ISUZ 48 Superseded by part number: 84187990 |
| 31. | 419830A1 | [1] | SMALL PIN | ISUOD 5 - L 6 |
| 32. | 289770A1 | [1] | PIN | ISUOD 8 - L 16 |
| 35. | 419831A1 | [1] | RING, FLYWHEEL | ISUZ 139 Superseded by part number: 71455913 |
| 38. | 419832A1 | [1] | WASHER | ISU |
| 40. | 419833A1 | [10] | BOLT | ISU Superseded by part number: 71455915 |
| 42. | 419842A1 | [2] | THRUST WASHER | ISU |
| 57. | 87384746 | [1] | DOWEL | ISU |
| 63. | 87384747 | [6] | PISTON | ISUGrade= Non |
| 68. | 87384748 | [6] | PISTON RINGS KIT | ISU |
| 73. | 87384749 | [6] | BEARING,CON.ROD | ISUBEARING, CON. ROD |
| 83. | 419835A1 | [6] | PISTON PIN | ISU |
| 84. | 419836A1 | [6] | PITMAN ASSY. | ISU |
| 85. | 419837A1 | [6] | BUSHING | ISU Superseded by part number: 72110267 |
| 86. | 419838A1 | [12] | BOLT | ISU |
| 88. | 419839A1 | [12] | NUT | ISU |
| 126. | 419840A1 | [12] | SNAP RING | ISU Superseded by part number: 72110270 |
| 149. | 419841A1 | [6] | PLUG | ISU |
