纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-025-01[01]) - INTAKE PIPE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
913 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 87532284 | [1] | INLET MANIFOLD | ISU |
| 7. | 87538790 | [6] | MANIFOLD GASKET | ISU |
| 20. | 419929A1 | [12] | NUT | ISUM10 Superseded by part number: 87596349 |
| 24. | 426055A1 | [12] | SPRING | ISU |
| 30. | 288553A1 | [2] | PLUG | ISU |
| 50. | 87538789 | [1] | PIPE | ISU |
| 94. | 288982A1 | [2] | BOLT | ISUM6 x 12 Superseded by part number: 87595952 |
| 95. | 76600223 | [2] | HOSE CLIP | ISU Superseded by part number: 84159872 |
| 97. | 87378549 | [1] | SENSOR | ISU |
| 153. | 87384766 | [1] | GASKET | ISU |
| 283. | 87384768 | [1] | HOSE | ISU |
| 320. | 289091A1 | [2] | PACKING | ISU |
| 363. | 87384769 | [1] | BOLT | ISU |
| 495. | 87384771 | [1] | PIPE | ISU |
| 568. | 426208A1 | [6] | BOLT | ISUM10 x 30 |
