纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-028-01[01]) - BREATHER New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
148 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 426076A1 | [1] | BREATHER | ISU |
| 9. | 426077A1 | [1] | GASKET | ISU Superseded by part number: 72110327 |
| 10. | 426078A1 | [1] | CLIP | ISUID 28.5 |
| 11. | 87384775 | [1] | TUBE,1090.00 mm | ISU |
| 24. | 87384779 | [4] | CLIP | ISU |
| 59. | 438027A1 | [1] | CLAMP | ISU Superseded by part number: 437887A1 |
| 84. | 355226A1 | [4] | BOLT | ISUM8 x 20 |
| 90. | 438022A1 | [1] | CLAMP | ISUL 250mm Superseded by part number: 288858A1 |
| 91. | 288993A1 | [2] | FLANGE BOLT | ISUM10 x 20 |
| 262. | 87384780 | [1] | BRACKET | ISU |
| 263A. | 443705A1 | [1] | BOLT | ISUM10 x 70 Superseded by part number: 87596456 |
| 263B. | 87524695 | [2] | BOLT | ISU |
