神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (03-031[01]) - BUCKET CYLINDER INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
630 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY12B00247F1 | [1] | | |
| 1. | YY12B00238F1 | [1] | | |
| 2. | YY12B01436P1 | [1] | PIN | KOB |
| 3. | HS18C12115G2 | [1] | SCREW,M12 x 115mm, Cl 10.9 | KOBCap |
| 4. | ZN18C12010 | [2] | NUT | KOB |
| 5. | B16T0442D19 | [1] | SHIM,62mm ID x 100mm OD x 1.6mm Thk | KOB1.6 |
| 6. | B16T0442D43 | [1] | SHIM,62mm ID x 100mm OD x 0.9mm Thk | KOB0.9 |
| 7. | B16T0442D56 | [1] | SHIM,62mm ID x 100mm OD x 0.5mm Thk | KOB0.5 |
| 8. | YN12B01610D1 | [2] | SHIM | KOB2.0 |
| 9. | YY01V00055F1 | [1] | BUCKET CYLINDER | KOB Superseded by part number: YY01V00055F5 |
