纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (02-027-01[01]) - EXHAUST PIPE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
460 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 2. | 426064A1 | [6] | MANIFOLD GASKET | ISU |
| 5. | 87384772 | [1] | EXHAUST MANIFOLD | ISU |
| 6. | 426066A1 | [1] | MANIFOLD | ISU |
| 18. | 87384773 | [18] | NUT | ISU |
| 34. | 87379734 | [18] | COLLAR | ISUL 28 |
| 47B. | 87384774 | [1] | EXHAUST MANIFOLD | ISU |
| 49. | 87328791 | [4] | STUD | ISUM10 x 25 L=47 |
| 58. | 362157A1 | [6] | STUD | CASM8 x 2 L=32 Superseded by part number: 87603352 |
| 155A. | 426074A1 | [3] | COMPOSITE RING | ISU |
| 155B. | 426075A1 | [1] | COMPOSITE RING | ISU Superseded by part number: 71456083 |
