纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (03-001-00[01]) - FUEL SYSTEM New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
324 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KHH10830 | [1] | FUEL HOSE,5400.00 mm | SUM |
| 2. | 157872A1 | [1] | PLASTIC-RUBBER TUBE | SUM4800 mm Superseded by part number: KHR21080 |
| 3. | 157915A1 | [2] | CLAMP | SUM |
| 4. | 166347A1 | [2] | BOLT,Sems, M10 x 30mm | SUMM10 x 30 |
| 5. | KWH10120 | [1] | SUPPORT | SUM |
| 6. | 166352A1 | [4] | BOLT | SUMM12 x 30 |
| 7. | 150848A1 | [2] | NIPPLE, LUBE | SUM |
| 8. | 157857A1 | [2] | ELBOW | SUM |
| 9. | KHH10700 | [1] | FUEL HOSE,1500.00 mm | SUM |
| 10. | 150441A1 | [1] | PLASTIC-RUBBER TUBE | SUM1300 mm Superseded by part number: KHR21060 |
| 11. | 157913A1 | [2] | CLAMP | SUM |
| 12. | KHH11130 | [1] | HYDRAULIC HOSE,13.00 mm ID x 1000.00 mm | SUM |
| 13. | 150433A1 | [1] | PLASTIC-RUBBER TUBE,22 mm ID, 27 mm OD, 600 mm Length | SUM600 mm Superseded by part number: KHR21060 |
| 15. | KHH0417 | [1] | SPACER | SUM Superseded by part number: KHH15210 |
| 16. | KHH0537 | [1] | MANIFOLD | SUM |
| 17. | 827-10090 | [4] | BOLT,Hex, M10 x 1.5 x 90mm, Cl 10.9 | CASM10 x 90 Superseded by part number: 828-10090 |
| 18. | 150409A1 | [4] | WASHER | SUMW M10 |
| 19. | KBH0950 | [1] | VALVE | SUM |
| 20. | KHH0498 | [1] | O-RING | SUM |
| 21. | KBH0953 | [1] | O-RING | SUM |
| 22. | 162335A1 | [1] | PLUG | SUM |
| 23. | KHH0538 | [2] | ADAPTER | SUM |
| 24. | KHH0539 | [2] | ELBOW | SUM |
| 25. | KHH10200 | [1] | FUEL HOSE,2800.00 mm | SUM |
| 26. | 158068A1 | [1] | PLASTIC-RUBBER TUBE | SUM2500 mm Superseded by part number: KHR21050 |
| 27. | KHH0405 | [2] | MOUNTING CLIP | SUM |
| 28. | KHH10220 | [1] | FUEL HOSE | SUM |
| 29. | 162635A1 | [1] | TUBE | SUM3300 mm Superseded by part number: KHR21050 |
| 31. | KHH0526 | [1] | FUEL HOSE,2800.00 mm | SUM |
| 34. | KWH0065 | [2] | SUPPORT | SUM |
| 35. | KUH10270 | [1] | SUPPORT | SUM |
| 36. | 152718A1 | [3] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 37. | KHR2581 | [14] | CLAMP | SUM |
| 38. | KHR2584 | [1] | CLAMP | SUM |
| 39. | KHJ1215 | [15] | BOLT,Spcl | SUMM8 x 25 |
| 40. | 150496A1 | [1] | MOUNTING CLIP | SUM250 mm |
