纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (03-002-00[01]) - FUEL TANK New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
875 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KWH0068 | [1] | FUEL TANK | SUM |
| 2. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 3. | 150492A1 | [1] | LOCKABLE FUEL CAP | SUM |
| 4. | 163804A1 | [1] | GASKET | SUM |
| 5. | KHH0500 | [1] | FILTER | SUM |
| 6. | 151322A1 | [1] | GASKET,3mm Thk | SUM |
| 7. | KWH10090 | [1] | COVER | SUM |
| 8. | 166052A1 | [8] | BOLT | SUMM10 x 25 Superseded by part number: 11106231 |
| 9. | 150847A1 | [1] | HYD CONNECTOR | SUM |
| 10. | 158923A1 | [1] | DRAIN VALVE | SUM |
| 11. | 102R020Y090R | [8] | BOLT | SUMM20 x 90 |
| 12. | KUJ0017 | [8] | SPACER | SUM |
| 13. | 153208A1 | [1] | SHIM | SUM |
| 14. | 153209A1 | [1] | SHIM | SUM |
| 15. | KWH0025 | [1] | SENSOR | SUM |
| 16. | 159698A1 | [1] | COVER | SUM |
| 17. | 151688A1 | [5] | SCREW,Phil Pan Hd, M5 x 12mm, W/ Wshr | CASM5 x 12 |
| 18. | 152591A1 | [1] | GASKET,2mm Thk | SUM |
| 19. | 159815A1 | [1] | GAUGE | SUM |
| 20. | 159816A1 | [1] | COVER | SUM |
| 21. | 157929A1 | [1] | FITTING | SUM |
| 22. | KHH0421 | [1] | FUEL HOSE,250.00 mm | SUM250 mm |
| 23. | KHH0405 | [1] | MOUNTING CLIP | SUM |
