纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (03-003-00[01]) - FUEL FILLING PUMP New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
218 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KHR11750 | [1] | FUEL PUMP | SUM |
| 2. | KHR11800 | [1] | FUEL PUMP | SUM |
| 3. | KHR11810 | [1] | SOLENOID VALVE | SUM |
| 4. | 627-12045 | [2] | BOLT,Hex, M12 x 1.75 x 45mm, Cl 10.9, Full Thd | CAS Superseded by part number: 86639031 |
| 5. | 150811A1 | [2] | WASHER | SUMW12 Superseded by part number: 86625255 |
| 6. | KHR12030 | [1] | BRACKET | SUM |
| 7. | 152718A1 | [4] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 8. | KHR12000 | [1] | FUEL HOSE | SUM5000 mm |
| 9. | KHR12010 | [1] | FUEL HOSE | SUM3600 mm |
| 10. | KHR11820 | [1] | LUBE NIPPLE | SUM |
| 11. | KHR11830 | [1] | ELBOW | SUM |
| 12. | 150881A1 | [4] | CLIP,ELECTRICAL | SUM |
| 13. | KHR2581 | [3] | CLAMP | SUM |
| 14. | KHJ1215 | [3] | BOLT,Spcl | SUMM8 x 25 |
| 15. | KHR4024 | [1] | ALARM | SUM |
| 16. | KHR1832 | [1] | SPECIAL BOLT | SUMM5 x 25 |
| 17. | KHR12070 | [1] | BRACKET | SUM |
| 19. | KHR12080 | [1] | BRACKET | SUM |
| 21. | KHR11510 | [1] | COVER | SUM |
| 22. | 156559A1 | [2] | BOLT,High Strength, Hex, M6 x 12mm, W/ LW | SUMM6 x 12 |
| 23. | KHR12900 | [1] | SWITCH | SUM |
| 24. | KHR3802 | [2] | RELAY | SUM24V |
| 25. | 159904A1 | [2] | COVER | SUM |
| 26. | KHR12060 | [1] | WIRE HARNESS | SUM |
| 27. | KHR2787 | [4] | CLAMP | SUM |
| 28. | 168103A1 | [1] | DECAL | SUM |
