神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (08-008[02]) - TIMING GEAR CASE Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
622 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | VAF121006016 | [1] | BOLT | KOBHexagon Socket |
| 2. | VA32G1104100 | [1] | GASKET | KOBGear Case |
| 3. | VA32G1112100 | [1] | FRONT PLATE | KOB |
| 4. | VA32G0714100 | [1] | GASKET | KOBFront Plate |
| 5. | VA3431103201 | [1] | POINTER | KOB |
| 6. | VAMF241250 | [1] | BOLT | KOBW/washer |
| 7. | VAF285004010 | [1] | PIN | KOBSpring |
| 8. | VAMF140240 | [7] | BOLT | KOBFlange |
| 9. | VAMF140245 | [2] | BOLT | KOBFlange |
| 10. | VAF200510030 | [3] | BOLT | KOBW/washer |
| 11. | VAMH000835 | [1] | BOLT | KOBFlange |
| 12. | VAMH000832 | [6] | FLANGE BOLT | KOB |
| 13. | VAMH000723 | [6] | BOLT | KOBFlange |
| 14. | VAF115510025 | [3] | BOLT | KOB |
| 15. | VA0593510020 | [1] | BOLT | KOBCoating |
| 16. | VAMF241251 | [2] | SCREW | KOBW/washer |
