纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (04-060-01[01]) - ELECTRICAL ACCESSORIES - ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
629 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 426652A1 | [1] | STARTING MOTOR | ISU7.0KW Superseded by part number: 76614470 |
| 2. | 426829A1 | [1] | ALTERNATOR,50A, W/ Pulley | ISU50A |
| 7. | 426270A1 | [3] | NUT | ISUM14 Superseded by part number: 84477146 |
| 16. | 87386229 | [1] | BOLT | ISUM14 x 123 |
| 17. | 426397A1 | [1] | WASHER,14mm ID x 26mm OD x 2.3mm Thk | ISU |
| 19. | 426655A1 | [1] | SUPPORT | ISU |
| 23. | 437982A1 | [1] | SUPPORT | ISU |
| 26. | 288635A1 | [1] | BOLT | ISUM10 x 60 Superseded by part number: 87601343 |
| 260. | 87386231 | [1] | SENSOR | ISU Superseded by part number: 84389010 |
| 293. | 87386234 | [1] | CABLE ASSY. | ISU |
| 424. | 167624A1 | [1] | RELAY,24V | SUM |
| 520. | 87379337 | [1] | SENSOR | ISU |
| 608. | 87378549 | [1] | SENSOR | ISU |
| 613. | 87540809 | [1] | ECU | ISU Superseded by part number: 87588714 |
| 898. | 87379342 | [1] | SENSOR | ISU |
