纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (04-060-02[01]) - ELECTRICAL ACCESSORIES - ENGINE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
183 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 101. | 288987A1 | [7] | BOLT | ISUM8 x 70 Superseded by part number: 87656138 |
| 259. | 438022A1 | [1] | CLAMP | ISU250 mm Superseded by part number: 288858A1 |
| 269. | 87386232 | [1] | SLEEVE | ISU |
| 690. | 87380194 | [2] | FITTING | ISU |
| 752. | 87379336 | [2] | GASKET | ISU |
| 813. | 87386235 | [1] | HARNESS | ISU |
| 836. | 288983A1 | [4] | BOLT | ISUM8 x 12 Superseded by part number: 71456268 |
| 915. | 87386237 | [7] | SPACER | ISU |
