| 1. | KUJ0042 | [2] | MANIFOLD VALVE | SUM |
| 2. | 164450A1 | [2] | O-RING | SUM |
| 3. | KUJ10180 | [2] | HYDRAULIC HOSE,31.80 mm ID x 1750.00 mm | SUM |
| 5. | 150124A1 | [4] | FLANGE | SUM |
| 6. | 108R012Y110R | [8] | BOLT | SUMM12 x 110 |
| 7. | 150811A1 | [8] | WASHER | SUMW 12 Superseded by part number: 86625255 |
| 19. | KUJ10170 | [1] | HYDRAULIC HOSE,31.80 mm ID x 2500.00 mm | SUM |
| 20. | KUJ10160 | [1] | HYDRAULIC HOSE,31.80 mm ID x 1920.00 mm | SUM |
| 23. | 108R014Y045R | [8] | BOLT,Hex Skt, M14 x 45mm, Cl 12.9 | SUMM14 x 45 |
| 24. | KUJ0213 | [2] | HOSE CLAMP | SUM |
| 25. | 152888A1 | [1] | PLATE, SPACER | SUMPLATE,SPACER |
| 26. | KUJ0036 | [2] | SPACER | SUM |
| 27. | 102R010Y110R | [2] | BOLT | SUMM10 x 110 |
| 28. | 150409A1 | [4] | WASHER | SUMW M10 |
| 29. | 829-1410 | [2] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
| 30. | KWJ10110 | [1] | SUPPORT | SUM |
| 31. | 166352A1 | [2] | BOLT | SUMM12 x 30 |
| 32. | KUJ0035 | [2] | HOSE CLAMP | SUM |
| 33. | KUJ0034 | [1] | SHEET | SUM |
| 37. | KWJ11040 | [1] | SUPPORT | SUM |
| 38. | 152718A1 | [2] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 39. | KWJ10070 | [1] | HYD. TUBE,34.7 mm ID x 42.7 mm OD | SUM |
| 41. | 862-14090 | [4] | HEX SOC SCREW,M14 x 90mm, Cl 12.9 | CAS Superseded by part number: 108R014Y090R |
| 42. | KWJ10100 | [1] | SPACER | SUM |
| 44. | KWJ10130 | [2] | CLAMP | SUM |
| 45. | 827-12100 | [2] | BOLT,Hex, M12 x 1.75 x 100mm, Cl 10.9 | CASM12 x 100 Superseded by part number: 86508622 |
| 47. | 829-1412 | [2] | NUT,M12, Cl 10 | CAS Superseded by part number: 337475 |
| 48. | KWJ10120 | [1] | SUPPORT | SUM |
| 50. | KUJ10240 | [1] | HYDRAULIC HOSE,25.40 mm ID x 1020.00 mm | SUM |
| 51. | KUJ10190 | [1] | HYDRAULIC HOSE,25.4mm ID x 1020mm L | SUM |
| 52. | 155211A1 | [2] | O-RING | SUM Superseded by part number: 86529541 |
| 53. | 153459A1 | [4] | FLANGE | SUM Superseded by part number: 86980728 |
| 54. | 862-10030 | [8] | HEX SOC SCREW,M10 x 30mm, Cl 12.9 | CAS Superseded by part number: 87016471 |
| 55. | KUJ10210 | [2] | SUPPORT | SUM |
| 56. | 627-12040 | [4] | BOLT,Hex, M12 x 1.75 x 40mm, Cl 10.9, Full Thd | CAS Superseded by part number: 337563 |
| 58. | KUJ10200 | [2] | CLAMP | SUM |
| 59. | KHJ2679 | [2] | HOSE CLAMP | SUM |
| 60. | 827-12090 | [4] | BOLT,Hex, M12 x 1.75 x 90mm, Cl 10.9 | CASM12 x 90 Superseded by part number: 412605 |
| 62. | KHJ1913 | [2] | PLUG | SUM |
| 63. | KHJ1361 | [2] | O-RING,0.07" Thk x 0.926" ID | SUM |
