纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-004-01[01]) - HYDRAULIC CIRCUIT - CONTROL VALVE SUPPLY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
770 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 3. | KUJ10180 | [2] | HYDRAULIC HOSE,31.80 mm ID x 1750.00 mm | SUM |
| 4. | 153626A1 | [2] | O-RING | SUM Superseded by part number: 164450A1 |
| 5. | 150124A1 | [4] | FLANGE | SUM |
| 8. | 108R014Y045R | [8] | BOLT,Hex Skt, M14 x 45mm, Cl 12.9 | SUMM14 x 45 |
| 9. | KUJ10220 | [2] | MANIFOLD VALVE | SUM |
| 10. | 108R014Y100R | [8] | BOLT | SUMM14 x 100 |
| 11. | 164450A1 | [2] | O-RING | SUM |
| 12. | KUJ0033 | [2] | FILTER | SUM |
| 13. | KUJ0039 | [4] | U-BOLT | SUM |
| 14. | 150409A1 | [16] | WASHER | SUMW M10 |
| 15. | 829-1410 | [16] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
| 16. | KUJ0352 | [1] | BRACKET | SUM |
| 17. | 627-12040 | [4] | BOLT,Hex, M12 x 1.75 x 40mm, Cl 10.9, Full Thd | CAS Superseded by part number: 337563 |
| 18. | 150811A1 | [4] | WASHER | SUMW 12 Superseded by part number: 86625255 |
| 19. | KUJ10170 | [1] | HYDRAULIC HOSE,31.80 mm ID x 2500.00 mm | SUM |
| 20. | KUJ10160 | [1] | HYDRAULIC HOSE,31.80 mm ID x 1920.00 mm | SUM |
| 64. | 152924A1 | [2] | PLUG | SUM |
| 65. | 154503A1 | [1] | O-RING | SUM |
