纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-008-01[01]) - HYDRAULIC CIRCUIT - LEAK-OFF RETURN (WITH VALVE, PRESSURE RELIEF) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
352 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 28. | KUJ0378 | [1] | BRACKET | SUM |
| 29. | 166352A1 | [3] | BOLT | SUMM12 x 30 |
| 30. | KUJ0371 | [1] | MANIFOLD VALVE | SUM |
| 32. | 157586A1 | [1] | ELBOW | SUM |
| 33. | 154503A1 | [1] | O-RING | SUM |
| 34. | 157584A1 | [1] | ELBOW | SUM |
| 35. | 154475A1 | [1] | O-RING | SUM |
| 36. | 150916A1 | [4] | ELBOW,90º, 3/8" O-Ring x 3/8" | SUM |
| 38. | 157580A1 | [2] | ELBOW,90º, 3/4" O-Ring x 3/4" | SUM |
| 40. | KNJ2060 | [1] | HOSE | SUM |
| 41. | 164231A1 | [1] | HYDRAULIC HOSE | SUM330 mm |
| 42. | KUJ0372 | [1] | MANIFOLD VALVE | SUM |
| 43. | 162012A1 | [1] | BRACKET | SUM |
| 44. | 166052A1 | [2] | BOLT | SUMM10 x 25 Superseded by part number: 11106231 |
| 45. | 166350A1 | [2] | BOLT | SUMM8 x 20 |
| 46. | 152128A1 | [4] | HYD CONNECTOR,3/8" NPT O-Ring x 3/8" NPT | SUM |
| 48. | KRJ0666 | [1] | HYDRAULIC HOSE,19.00 mm ID x 830.00 mm | SUM |
| 49. | 151654A1 | [2] | HYD CONNECTOR,3/4" NPT O-Ring x 3/4" NPT | SUM |
| 55. | KUJ0373 | [1] | MANIFOLD VALVE | SUM |
| 59. | KUJ10930 | [1] | HYDRAULIC HOSE,1750.00 mm | SUM |
| 60. | 157867A1 | [1] | PLASTIC-RUBBER TUBE | SUM1500 mm Superseded by part number: KHR21080 |
| 61. | 150071A1 | [2] | MOUNTING CLIP | SUM |
