神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (05-009[00]) - SUN VISOR Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
436 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | LQ55C01002F1 | [1] | PANEL | SM |
| 1-1. | NSS | [1] | NOT SOLD SEPARAT | CONCover |
| 1-2. | LQ55C01003P1 | [1] | GASKET | SM |
| 3. | ZM73C12025 | [2] | BOLT,M12x25mm - Course Thread | KOB |
| 4. | LQ55C01015P1 | [1] | GASKET | SM Superseded by part number: LQ55C01027P1 |
| 5. | YT50C01020P1 | [6] | RETAINER | KOB |
| 6. | YN55C01025P1 | [6] | WASHER | KOB |
| 7. | ZS18C08012 | [4] | SCREW,Hex, M8 x 12mm | KOB |
| 8. | ZW16H08000 | [6] | WASHER | KOB |
| 9. | ZS18C08016 | [2] | SCREW,Hex, M8 x 16mm | KOB |
| 10. | ZW16P12000 | [6] | WASHER | KOB |
| 13. | LC55C01001P1 | [1] | BRACKET | SM |
