| 1. | KUJ0224 | [1] | HYDRAULIC HOSE,31.80 mm ID x 2000.00 mm | SUM |
| 2. | KUJ0225 | [1] | HYDRAULIC HOSE,31.80 mm ID x 2100.00 mm | SUM |
| 3. | 150124A1 | [8] | FLANGE | SUM |
| 4. | 862-14040 | [8] | HEX SOC SCREW,M14 x 40mm, Cl 12.9 | CAS |
| 5. | 108R014Y045R | [8] | BOLT,Hex Skt, M14 x 45mm, Cl 12.9 | SUMM14 x 45 |
| 6. | 164450A1 | [4] | O-RING | SUM |
| 7. | 152888A1 | [1] | PLATE, SPACER | SUMPLATE,SPACER |
| 8. | KUJ0213 | [2] | HOSE CLAMP | SUM |
| 9. | KUJ0036 | [2] | SPACER | SUM |
| 10. | 827-10090 | [2] | BOLT,Hex, M10 x 1.5 x 90mm, Cl 10.9 | CASM10 x 90 Superseded by part number: 828-10090 |
| 11. | 150409A1 | [2] | WASHER | SUMW M10 |
| 12. | KUJ0058 | [1] | MANIFOLD VALVE | SUM |
| 13. | 102R014Y025R | [4] | BOLT | SUMM14 x 25 |
| 14. | 150418A1 | [4] | WASHER | SUMW M14 |
| 15. | KUJ0057 | [1] | BRACKET | SUM |
| 16. | 152718A1 | [4] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 17. | KUJ10290 | [1] | HYDRAULIC HOSE,25.40 mm ID x 680.00 mm | SUM |
| 18. | KUJ0062 | [1] | HYDRAULIC HOSE,25.40 mm ID x 700.00 mm | SUM |
| 19. | KUJ10270 | [1] | HYDRAULIC HOSE,25.40 mm ID x 1040.00 mm | SUM |
| 20. | KUJ10280 | [1] | HYDRAULIC HOSE,25.40 mm ID x 1080.00 mm | SUM |
| 21. | 153459A1 | [12] | FLANGE | SUM Superseded by part number: 86980728 |
| 22. | 862-10030 | [24] | HEX SOC SCREW,M10 x 30mm, Cl 12.9 | CAS Superseded by part number: 87016471 |
| 23. | 155211A1 | [6] | O-RING | SUM Superseded by part number: 86529541 |
| 24. | 153458A1 | [4] | FLANGE | SUM Superseded by part number: 71404407 |
| 26. | 155210A1 | [2] | O-RING | SUM |
| 27. | KUJ10300 | [2] | MANIFOLD VALVE | SUM |
| 28. | 108R010Y090R | [8] | BOLT | SUMM10 x 90 |
| 29. | 152210A1 | [2] | COVER | SUM Superseded by part number: 170036A1 |
| 30. | KWJ11180 | [1] | HYD. TUBE,52.9 mm ID x 60.5 mm OD | SUM |
| 31. | 862-12035 | [4] | HEX SOC SCREW,M12 x 35mm, Cl 12.9 | SUM |
| 32. | 154681A1 | [1] | O-RING | SUM |
| 33. | 157581A1 | [2] | ELBOW,90º, 1" O-Ring x 1" | SUM |
| 34. | 154523A1 | [1] | O-RING | SUM |
| 35. | KUJ10310 | [2] | HYDRAULIC HOSE,25.40 mm ID x 670.00 mm | SUM |
| 36. | 157587A1 | [2] | ELBOW | SUM |
