神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (02-012[02]) - HYDRAULIC LINES, LOWER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
225 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY02H01328P1 | [1] | TUBE | KOB |
| 2. | YY02H01329P1 | [1] | TUBE | KOB |
| 3. | YY02H01330P1 | [1] | TUBE | KOB |
| 4. | YY02H01331P1 | [1] | TUBE | KOB |
| 5. | YN02H01511D1 | [4] | HYDRAULIC HOSE | KOB |
| 6. | ZX23M04210 | [2] | HOSE | KOB |
| 7. | 2420Z1224D4 | [4] | HOSE | KOB |
| 8. | YY02H01336P1 | [1] | TUBE | KOB |
| 9. | YY02H01337P1 | [1] | TUBE | KOB |
| 10. | YY02H01338P1 | [1] | TUBE | KOB |
| 11. | YY02H01339P1 | [1] | TUBE | KOB |
| 12. | YY02H01078P1 | [2] | CLAMP | KOB |
| 13. | ZW16H12000 | [2] | WASHER | KOB |
| 14. | ZS18C12050 | [2] | SCREW,Hex, M12 x 50mm | KOBCap |
| 15. | ZE72X06000 | [4] | PLUG | KOB |
| 16. | ZE72X08000 | [4] | PLUG | KOB |
