纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-039-00[01]) - HYDRAULIC CIRCUIT - SMALL FLOW New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
398 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 74. | 161841A1 | [1] | HYD CONNECTOR | SUM |
| 75. | 152127A1 | [1] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 76. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 77. | 167321A1 | [2] | TEE | SUM |
| 78. | 161704A1 | [2] | ADAPTER | SUM |
| 79. | KHJ11460 | [2] | ADAPTER | SUM |
| 80. | KHR10800 | [2] | PRESSURE SWITCH | SUM Superseded by part number: KHR24010 |
| 82. | 150067A1 | [2] | MOUNTING CLIP | SUM150 mm |
| 84. | KHJ12840 | [1] | HYDRAULIC HOSE | SUM5650 mm |
| 85. | KHJ12630 | [1] | CHAIN (CE) | SUM905 mm |
| 86. | 151872A1 | [1] | HOSE ASSY. | SUM850 mm |
| 88. | 150496A1 | [1] | MOUNTING CLIP | SUM250 mm |
| 89. | KHJ1178 | [1] | ELBOW | SUM |
| 90. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 92. | 159497A1 | [2] | TEE | SUM |
| 94. | KHJ1973 | [1] | VALVE | SUM Superseded by part number: KHJ17120 |
| 95. | 827-8045 | [2] | BOLT,Hex, M8 x 1.25 x 45mm, Cl 10.9 | CAS Superseded by part number: 16044131 |
| 96. | 153081A1 | [2] | WASHER | SUMW M8 |
| 97. | KWJ10870 | [1] | SUPPORT | SUM |
| 98. | 152718A1 | [2] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 101. | 159044A1 | [1] | HOSE ASSY. | SUM |
| 104. | 158186A1 | [1] | PRESSURE RELIEF VALVE | SUM Superseded by part number: KHJ26180 |
| 105. | 162654A1 | [1] | HYD CONNECTOR | SUM |
| 110. | 152276A1 | [1] | HOSE,63mm ID x 550mm L | SUM |
| 111. | 159019A1 | [1] | HOSE ASSY. | SUM900 mm |
| 120. | 159007A1 | [1] | HOSE | SUM2000 mm Superseded by part number: KAJ3099 |
| 121. | 158130A1 | [1] | HOSE,6.3mm ID x 1350mm L | SUM3350 mm |
| 122. | KHR2584 | [3] | CLAMP | SUM |
| 123. | KHJ1215 | [3] | BOLT,Spcl | SUMM8 x 25 |
| 127. | 150071A1 | [1] | MOUNTING CLIP | SUM380 mm |
| 128. | KHR3353 | [1] | HARNESS | SUM |
