| 1. | KUJ10620 | [1] | HYD. TUBE,34.7 mm ID x 42.7 mm OD | SUM |
| 2. | 164450A1 | [1] | O-RING | SUM |
| 3. | 108R014Y045R | [4] | BOLT,Hex Skt, M14 x 45mm, Cl 12.9 | SUMM14 x 45 |
| 4. | KWJ10510 | [2] | CLAMP | SUM |
| 5. | 827-12100 | [2] | BOLT,Hex, M12 x 1.75 x 100mm, Cl 10.9 | CASM12 x 100 Superseded by part number: 86508622 |
| 6. | 150811A1 | [4] | WASHER | SUMW12 Superseded by part number: 86625255 |
| 7. | 829-1412 | [2] | NUT,M12, Cl 10 | CAS Superseded by part number: 337475 |
| 8. | KUJ10590 | [1] | SUPPORT | SUM |
| 9. | 152718A1 | [2] | BOLT,Spcl, Hex Wshr, M12 x 25mm, Cl 10.9 | SUM |
| 10. | KUJ10610 | [1] | HYDRAULIC HOSE,31.80 mm ID x 1130.00 mm | SUM |
| 11. | 168211A1 | [1] | O-RING | SUM |
| 12. | KTJ0169 | [2] | FLANGE | SUM |
| 13. | 862-16050 | [4] | HEX SOC SCREW,M16 x 50mm, Cl 12.9 | CASM16 x 50 Superseded by part number: 9817243 |
| 15. | 150124A1 | [2] | FLANGE | SUM |
| 17. | KSJ2740 | [1] | MANIFOLD | SUM |
| 18. | 166373A1 | [4] | BOLT,Sems, M16 x 40mm | SUMM16 x 40 |
| 19. | KUJ10640 | [1] | SUPPORT | SUM |
| 20. | 165929A1 | [4] | BOLT,Sems, M16 | SUMM16 x 50 |
| 21. | KUJ0453 | [2] | HYDRAULIC HOSE,38.10 mm ID x 2580.00 mm | SUM |
| 28. | 163436A1 | [1] | MANIFOLD | SUM |
| 29. | 166352A1 | [4] | BOLT | SUMM12 x 30 |
| 30. | KUJ10630 | [1] | SUPPORT | SUM |
| 32. | 163435A1 | [1] | COVER | SUM |
| 33. | 154640A1 | [1] | O-RING | SUM |
| 34. | 862-16030 | [4] | HEX SOC SCREW,M16 x 30mm, Cl 12.9 | CAS Superseded by part number: 863-16030 |
| 35. | 162656A1 | [1] | VALVE | SUM |
| 36. | KUJ10660 | [1] | HYDRAULIC HOSE,31.80 mm ID x 930.00 mm | SUM |
| 38. | 157856A1 | [2] | CLAMP BRACKET | SUM |
| 39. | 862-10030 | [4] | HEX SOC SCREW,M10 x 30mm, Cl 12.9 | CAS Superseded by part number: 87016471 |
| 40. | 157588A1 | [1] | ELBOW | SUM |
| 41. | KWJ0048 | [1] | VALVE SECTION | SUM |
| 43. | 862-14090 | [4] | HEX SOC SCREW,M14 x 90mm, Cl 12.9 | CAS Superseded by part number: 108R014Y090R |
| 44. | KUJ10560 | [1] | HYDRAULIC HOSE,31.80 mm ID x 1030.00 mm | SUM |
| 45. | 159047A1 | [2] | ADAPTER | SUM |
| 46. | 154559A1 | [1] | O-RING | SUM |
| 47. | KWJ0051 | [1] | VALVE SECTION | SUM |
| 48. | KWJ0052 | [1] | VALVE SECTION | SUM |
| 49. | 154721A1 | [2] | O-RING,99.4mm ID x 3.1mm Width | SUM |
| 50. | 827-16090 | [8] | BOLT,Hex, M16 x 2 x 90mm, Cl 10.9 | CAS Superseded by part number: 86521733 |
| 51. | KUJ0159 | [1] | FILTER | SUM |
| 52. | KUJ0160 | [1] | FILTER, ELEMENT | SUM |
| 53. | 159706A1 | [1] | INDICATOR | SUM |
| 55. | KUJ0119 | [1] | BRACKET | SUM |
| 57. | KUJ10670 | [1] | HYDRAULIC HOSE,31.80 mm ID x 1950.00 mm | SUM |
| 60. | 157582A1 | [1] | ELBOW,90º, 1 1/4" O-Ring x 1 1/4" | SUM |
| 62. | KUJ0252 | [4] | HOSE CLAMP | SUM |
| 63. | KUJ0034 | [2] | SHEET | SUM |
| 64. | KUJ0036 | [4] | SPACER | SUM |
| 65. | 102R010Y110R | [4] | BOLT | SUMM10 x 110 |
| 66. | 829-1410 | [2] | NUT,M10 x 1.5, Cl 10.9 | CAS Superseded by part number: 86500689 |
| 67. | 150409A1 | [6] | WASHER | SUMW M10 |
| 68. | KUJ10680 | [1] | SUPPORT | SUM |
| 69. | KUJ0253 | [1] | BRACKET | SUM |
