神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-010[00]) - AIR CLEANER ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
615 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY11P00009F1 | [1] | Air | |
| 1. | YY11P00008F1 | [1] | CLEANER ASSY. | KOBAir |
| 2. | YY11P00008S001 | [1] | BOX | SM |
| 3. | YY11P00008S002 | [1] | ELEMENT | KOBFilter |
| 4. | YY11P00008S003 | [1] | ELEMENT | KOBFilter |
| 5. | YY11P00008S004 | [1] | GUARD | SMCover Assy. |
| 6. | YX11P00002S004 | [1] | VALVE | KOBAssy. |
| 7. | YY11P00008S006 | [1] | O-RING | KOB |
| 8. | YY11P00008S007 | [1] | WARNING LIGHT | SMIndicator Superseded by part number: LV11P01017F1 |
| 9. | YY11P01035P1 | [1] | FLEXIBLE HOSE | KOBAir |
| 10. | YY11P01028P1 | [1] | FLEXIBLE HOSE | KOBAir |
| 11. | YY11P01032P1 | [1] | FLEXIBLE HOSE | KOBAir |
| 12. | YY11P01049P1 | [1] | RUBBER | KOB |
| 13. | ZC16X07000 | [1] | CLIP | KOB |
| 14. | ZC16X09100 | [2] | CLIP | KOB |
| 15. | ZC16X11000 | [2] | CLIP | KOB |
| 16. | ZM22C08016 | [4] | BOLT | KOBSems |
