神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-011[00]) - MUFFLER ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
278 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY12P00010F1 | [1] | | |
| 1. | YY12P00012P1 | [1] | MUFFLER | KOB |
| 2. | YY12P01021P1 | [1] | BRACKET | KOB |
| 3. | YN12P01023P1 | [1] | CLAMP,60.5mm - 65mm | KOBAssy. |
| 4. | HR91C08000GK | [2] | CLAMP | KOBU-Bolt |
| 5. | HX11Y07074DX | [1] | HOSE | KOB Superseded by part number: HX11Y07100DX |
| 6. | ZM73C10025 | [4] | BOLT,M10x25mm - Course Thread | KOBSems |
| 7. | ZS18C10035 | [2] | SCREW,Hex, M10 x 35mm | KOBCap |
| 8. | ZW16P10000 | [2] | WASHER | KOB |
| 9. | ZN18C10008 | [2] | NUT | KOB |
| 10. | ZN18C08007 | [8] | NUT | KOBM08x1.25mm |
| 11. | ZC16X01200 | [1] | CLIP,8mm - 15mm | KOB |
| 12. | YB12P01013P1 | [1] | TUBE | KOBExhaust Superseded by part number: YB12P01013P2 |
| 13. | ZM73C10020 | [4] | BOLT,M10x20mm - Course Thread | KOBSems |
