神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-012[01]) - FUEL LINES Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
132 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY21P00016F1 | [1] | | |
| 1. | LQ53V00006P1 | [1] | RADIATOR | SMOil |
| 2. | YY05P01308P1 | [1] | BRACKET, SUPPORTING | KOB |
| 3. | HX11F06036DX | [1] | HOSE,9.7mm ID x 360mm L | KOB |
| 4. | HX11F06120DX | [1] | HOSE ASSY.,9.70mm ID x 1200mm L | KOB |
| 5. | HX11F06400DX | [1] | HOSE ASSY.,9.70mm ID x 4000mm L | KOB |
| 6. | HX11F06480DX | [1] | HOSE ASSY.,9.70mm ID x 4800mm L | KOB |
| 7. | YY21P01023P1 | [1] | HOSE ASSY. | KOB |
| 8. | HX81X19024DX | [1] | TUBE | KOB |
| 9. | HX81X19110DX | [1] | PIPE | KOB |
| 10. | HX81X19260DX | [1] | TUBE | KOB |
| 11. | HX81X19390DX | [1] | PIPE | KOB |
| 12. | HX81X19470DX | [1] | PIPE | KOB |
| 13. | PH05P01088D7 | [10] | CLIP,13.6mm - 17.5mm | KOB |
| 14. | PY01P01043D2 | [20] | CABLE TIE,4.60mm W x 202mm L | KOB Superseded by part number: YT50C01100P1 |
| 15. | PY01P01043D3 | [4] | CABLE TIE,188mm L | KOB |
| 16. | YN13E01375P1 | [5] | CLIP,M8 x 8.20mm Shank | KOB |
| 17. | ZM73C08016 | [8] | BOLT,M8x16mm - Course Thread | KOBSems |
| 18. | YN68H01106P1 | [1] | COVER | KOB |
