纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-096-00[01]) - HYDRAULIC CIRCUIT - PLUG, BLANK-OFF (WITH SELF-DETACHING COUNTERWEIGHT SYSTEM) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
299 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | KHV0361 | [1] | ADAPTER | SUM |
| 2. | 152127A1 | [1] | HYD CONNECTOR,1/4" NPT O-Ring x 1/4" NPT | SUM |
| 3. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 4. | 150933A1 | [1] | ELBOW | SUM |
| 6. | 157584A1 | [1] | ELBOW | SUM |
| 7. | 154475A1 | [1] | O-RING | SUM |
| 8. | 158183A1 | [1] | ELEC CONNECTOR,Male | SUM |
| 10. | 158186A1 | [1] | PRESSURE RELIEF VALVE | SUM Superseded by part number: KHJ26180 |
| 11. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
| 18. | 159497A1 | [1] | TEE | SUM |
