纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-097-00[01]) - HYDRAULIC CIRCUIT - PLUG, BLANK-OFF (WITHOUT SELF-DETACHING COUNTERWEIGHT SYSTEM) New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
431 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | 152924A1 | [1] | PLUG | SUM |
| 2. | 154503A1 | [1] | O-RING | SUM |
| 3. | 159002A1 | [2] | PLUG | SUM |
| 4. | 154467A1 | [1] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 5. | 153105A1 | [1] | PLUG | SUM |
| 6. | 154475A1 | [1] | O-RING | SUM |
| 7. | 159481A1 | [1] | ADAPTER | SUM |
| 9. | 163814A1 | [1] | ELBOW | SUM |
| 10. | 150913A1 | [1] | ELBOW,90º, 1/4" O-Ring x 1/4" | SUM |
