纽荷兰零件查询(E805) - CRAWLER EXCAVATOR TIER 3 (7/06-) (08-205-00[01]) - CONTROL VALVE New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
695 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 85. | NSS | [1] | NOT SERVICED SEPARATELY | CONHousing |
| 91. | 108R012Z030N | [20] | BOLT | SUM |
| 92. | LW00266 | [3] | COVER | SUM |
| 93. | 156263A1 | [1] | CAP | SUM |
| 94. | 154475A1 | [2] | O-RING | SUM |
| 95. | LBQ6226 | [10] | O-RING | SUM |
| 97. | LJ00580 | [1] | VALVE, PRESSURE RELI | SUMEF |
| 98. | 154555A1 | [1] | O-RING | SUM |
| 99. | LW00268 | [5] | COVER | SUM |
| 100. | LK00233 | [1] | CAP | SUM |
| 101. | LW00269 | [2] | COVER | SUM |
| 102. | LK00238 | [2] | PLUG | SUM |
| 103. | 154467A1 | [11] | O-RING,10.8mm ID x 2.4mm Width | SUM |
| 142. | 160306A1 | [5] | CAP | SUM |
| 149. | LJ00595 | [1] | ORIFICE | SUM |
| 150. | LB00433 | [1] | BALL | SUM |
| 151. | LR00424 | [1] | SPRING SEAT | SUM |
| 152. | LG00259 | [1] | COMPRESSION SPRING | SUM |
| 154. | LJ00594 | [1] | ORIFICE | SUM |
| 155. | LJ00878 | [2] | VALVE, PRESSURE RELI | SUMEF |
| 156. | 154525A1 | [1] | O-RING | SUM |
| 157. | 153973A1 | [1] | BACK-UP RING | SUMRING, BACK-UP |
| 158. | 154493A1 | [1] | O-RING | SUM |
| 159. | 156264A1 | [2] | CAP | SUM |
| 160. | 154523A1 | [2] | O-RING | SUM |
| 161. | LK00231 | [2] | CAP | SUM |
| 162. | 156079A1 | [3] | SPRING | SUM |
| 163. | LJ00600 | [3] | CHECK VALVE | SUM |
| 164. | 154006A1 | [3] | BACK-UP RING | SUMRING, BACK-UP |
| 165. | 154535A1 | [3] | O-RING | SUM |
| 166. | LR00425 | [1] | CAP | SUM |
| 171. | LK005440 | [2] | PLUG | SUM |
| 172. | 154491A1 | [2] | O-RING | SUM |
| 173. | 160901A1 | [1] | CAP | SUM |
