神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-019[03]) - VALVE INSTALLATION Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
849 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY30V00052S003 | [2] | CAP | KOB |
| 2. | YY30V00052S004 | [1] | SEAT | KOB |
| 3. | YY30V00052S005 | [1] | SEAT | KOB |
| 4. | YY30V00052S006 | [2] | SPRING | KOB |
| 5. | 2436R668S3 | [2] | O-RING | KOB |
| 6. | ZS23C06018 | [2] | SCREW,Hex Socket Head, M6 x 18mm | KOBCap |
| 7. | 2436R331S10 | [1] | POPPET | KOB |
| 8. | 2436U389S12 | [1] | SPRING | KOB |
| 9. | 45Z91D84 | [1] | O-RING | KOB |
| 10. | YY30V00052S012 | [2] | SCREW | KOBCap |
| 11. | 2436R1120S3 | [1] | SPACER | KOB |
| 12. | 2436R336S15 | [1] | O-RING | KOB |
| 13. | 2436R1119S10 | [1] | O-RING | KOB |
| 14. | 2436R1119S11 | [1] | BACK-UP RING | KOB |
| 15. | 2436U388S5 | [1] | O-RING | KOB |
| 16. | 2436U388S25 | [1] | O-RING | KOB |
| 17. | ZD12P01000 | [1] | O-RING | KOB |
| 18. | 2436R378S13 | [1] | O-RING | KOB |
| 19. | 2436R378S14 | [1] | BACK-UP RING | KOB |
| 20. | 2436R378S15 | [1] | O-RING | KOB |
| 21. | 2436R378S16 | [1] | BACK-UP RING | KOB |
| 22. | 2436U388S5 | [1] | O-RING | KOB |
| 23. | 2436U388S25 | [1] | O-RING | KOB |
| 24. | ZD12P01000 | [1] | O-RING | KOB |
