神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-020[01]) - HYDRAULIC LINES, PUMP Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
120 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YY30H00061F1 | [1] | Pump | |
| 1. | YY30H00057F1 | [1] | Pump | |
| 2. | YY30H01023D1 | [1] | HOSE | KOB |
| 3. | YY30H01024D1 | [1] | HOSE | KOB |
| 4. | YY30H01075P1 | [2] | RUBBER PAD | KOB |
| 5. | YY30H01076F1 | [1] | CLAMP | KOB |
| 6. | YY30H01077P1 | [1] | CLAMP | KOB |
| 7. | YY30H01028P1 | [1] | INSULATION | KOB |
| 8. | PM21C01152D1 | [2] | WEATHERSEAL STRIP | KOB |
| 9. | YY30H01022P1 | [1] | CLAMP | KOB |
| 10. | ZE13X12000 | [4] | CLAMP | KOBHalf |
| 11. | HS18C10140G1 | [2] | SCREW,M10 x 140mm, Cl 10.9 | KOBCap |
| 12. | ZM73C10020 | [1] | BOLT,M10x20mm - Course Thread | KOBSems |
| 13. | HM83C10035G1 | [8] | BOLT | KOBSems |
| 14. | ZW16H10000 | [2] | WASHER | KOB |
| 15. | ZY26X06115 | [2] | SPACER | KOB |
| 16. | ZD12P02600 | [2] | O-RING | KOB |
