神钢零件查询(ED150-2) - BLADE RUNNER EXCAVATOR/DOZER ASN LH01-01001 (1/09-12/12) (01-021[03]) - HYDRAULIC LINES, UPPER Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
294 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YY03H00089F1 | [1] | Upp. | |
| 2. | YY32H01038D3 | [1] | HOSE | KOB |
| 3. | YY03H01346D1 | [1] | HOSE ASSY. | KOB |
| 4. | YY03H01345D1 | [1] | HOSE ASSY. | KOB |
| 5. | ZE12X16000 | [2] | CLAMP | KOBHalf |
| 6. | HH25S16016G1 | [1] | HYD CONNECTOR | KOB |
| 7. | ZG23F10012 | [1] | HYD CONNECTOR | KOB |
| 8. | HM83C10035G1 | [4] | BOLT | KOBSems |
| 9. | HM83C12035G1 | [2] | BOLT | KOBSems |
| 10. | ZD12A01600 | [1] | O-RING | KOB |
| 11. | ZD12P03400 | [1] | O-RING,0.139" Thk x 1.296" ID, -219, Cl 6, 90 Duro | KOB |
| 12. | ZD12P03800 | [1] | O-RING | KOB |
| 13. | ZE72X12000 | [1] | PLUG | KOB |
| 14. | ZM73C12030 | [1] | BOLT,M12x30mm - Course Thread | KOBSems |
| 15. | YX32H01011P1 | [1] | BUSHING,33mm ID x 49mm OD x 50mm L | KOB |
| 16. | PY01P01043D3 | [1] | CABLE TIE,188mm L | KOB |
