神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (05-004) - AIR CLEANER ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
283 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 2446R277F1 | [1] | AIR CLEANER | KOBASSY |
| 1. | 2446R254S1 | [1] | NUT | KOBWING |
| 2. | 2446R254S2 | [1] | RING | KOB |
| 3. | 2446R254S3 | [2] | NUT | KOBWING |
| 4. | 2446R254S4 | [2] | WASHER | KOB |
| 5. | 2446R277S5 | [1] | AIR FILTER | KOBOUTER |
| 6. | 2446R277S6 | [1] | AIR FILTER | KOBINNER |
| 7. | 2446R255S7 | [1] | EJECTOR | KOBDUST |
| 8. | 2446R277S8 | [1] | COVER | KOB Superseded by part number: 2446R255S8 |
