神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (05-009) - CONTROLLER ASSEMBLY Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
991 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100J20921F1 | [1] | CONTROLLER ASSY | |
| 1. | 2414N5501 | [1] | BOX | KOB(LEVEL 3-BOTTOM) |
| 2. | 2418P33698 | [1] | PLATE | KOB(LEVEL 2-MIDDLE) |
| 3. | 2418P31019 | [1] | PLATE | KOB(LEVEL 1-TOP) |
| 4. | 2420R1164 | [1] | SHEET | KOB |
| 5. | 2479U1290 | [1] | RELAY | KOBASSY (R-8 TWO SPEED TRAVEL) |
| 6. | YN24E00001F2 | [1] | RELAY | KOBASSY (R-6 WORKLIGHTS, HORN) |
| 7. | 2480U306 | [1] | FLASHER UNIT | KOB(C-3 SWING LIGHTS) |
| 9. | 2484R166D1 | [1] | RESISTOR,62 Ohm | KOB(E-2 KPSS RELEASE) |
| 10. | 2479U1447 | [1] | RELAY,24V, 4 Sec Delay | KOBTIMER (R-9 TRAVEL ALARM) |
| 11. | 2480U371F4 | [1] | CONTROL | KOB(C-2 CLUSTER GAUGE) |
| . . | 2480U371F4R | [1] | REMAN-ELECT GAUGE | KOBED180 BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 |
| . . | 2480U371F4C | [1] | CORE GAUGE ELECT | KOBReturn Number |
| 12. | 2487U41F2 | [1] | FUSE BOX | KOB(E-1) (SEE FIGURE 05-011) |
| 13. | YN24S00001P1 | [1] | RELAY,24V, 10 Amp | KOB(R-3 KEY SWITCH) |
| . . | YN24S00001P1 | [1] | RELAY,24V, 10 Amp | KOB(R-5 WORKING LIGHT) (OPT.) |
| 14. | 2479U1290 | [1] | RELAY | KOBASSY (R-12 WARM-UP UNIT) (OPT.) (SEE FIGURE 09-004) |
| 18. | 2479R1366 | [1] | RELAY | KOB(R-7 INTERMITTENT WIPER) |
| 19. | 2420Z1188 | [1] | GROMMET | KOB |
| 20. | ZM46C04016 | [1] | SCREW | KOBM04x0.7x16mm (Incls. Washer & Lockwasher) |
| 21. | ZM66C06016 | [18] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| . . | ZM66C06016 | [1] | BOLT | KOBM06x1.0x16mm (Incls. Washer & Lockwasher) |
| 22. | ZM66C06020 | [10] | BOLT | KOBM06x1.0x20mm (Incls. Washer & Lockwasher) |
| 23. | ZW16P04000 | [1] | WASHER | KOBID 04 x OD 09 x Th 0.8mm |
| 24. | ZW16X06000 | [8] | WASHER | KOBID 06 x OD 12.5 x Th 1.6mm Superseded by part number: 86588450 |
| 30. | YN50S01002P1 | [1] | SWITCH | KOB(SW-3 KPSS RELEASE) |
| 33. | 2479R2401 | [1] | RELAY | KOB(R-11 ENGINE STOP) |
| 34. | ZM66C05016 | [1] | BOLT | KOBM05x0.8x16mm (Incls. Washer & Lockwasher) |
| 35. | YN22M01006D7 | [2] | BUSHING | KOB(ANTI-SCUFF STRIP) |
| 38. | 24100J20922F1 | [1] | HARNESS ASSY (CONTROLLER) (SEE FIGURE 06-004) | |
