神钢零件查询(ED180) - BLADE RUNNER EXCAVATOR/DOZER ASN YLU0001 (1/99-12/01) (05-013) - HEATER ASSEMBLY (W/AC) Kobelco
广数供应链运营团队, 15 02月, 2025，浏览：
239 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | 24100N8588F2 | [1] | HEATER ASSY OPTIONAL (W/AC) | |
| 3. | 2444R2542D5 | [1] | FLEXIBLE HOSE | KOBN/A HOSE- SUB'D HOSE |
| 4. | 2444R2542D3 | [2] | FLEXIBLE HOSE | KOBN/A HOSE- SUB'D |
| 5. | 2444R2542D1 | [2] | FLEXIBLE HOSE | KOBN/A HOSE- SUB'D |
| 6. | 2444R2542D6 | [1] | FLEXIBLE HOSE | KOB |
| 8. | 2432Z909D3 | [10] | CLIP | KOBCLAMP Superseded by part number: ZC16X07000 |
| 13. | 24100U1476F2 | [1] | HEATER | KOBASSY (SEE FIGURE 05-016) |
| 14. | 24100U1497F1 | [1] | PANAL ASSY (HEATER/AC) (SEE FIGURE 05-014) | |
