纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.001[00]) - VALVE ASSEMBLY, CONTROL (LC30V00101F1) (HC001), FIGURE 1 OF 5 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
844 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN30V00101F1 | [1] | VALVE, CONTROL | KOBAssembly, Figure 1 of 5, Start Serial: 0 Superseded by part number: YN30V00101F6 |
| 163. | ZD12P01500 | [11] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 606. | YN30V00120F1 | [2] | VALVE | KOBAssembly, Bypass Superseded by part number: YN30V00120F2 |
| 977. | NA | [1] | NOT SERVICED | FORName Plate |
