纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (NA) - ASN N7DA21001 (1/07-) (8.002[00]) - VALVE ASSEMBLY, CONTROL (LC30V00101F1) (HC001), FIGURE 2 OF 5 New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
500 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN30V00101F1 | [1] | VALVE, CONTROL | KOBAssembly, Figure 2 of 5, Start Serial: 0 Superseded by part number: YN30V00101F6 |
| 101. | NA | [1] | NOT SERVICED | FORBody |
| 154. | YN30V00001S154 | [3] | PLUG | KOB |
| 155. | YW30V00001S155 | [2] | PLUG | KOB |
| 162. | ZD12G03000 | [15] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 163. | ZD12P01500 | [11] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 164. | ZD12P02400 | [19] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 169. | ZD12P01800 | [2] | O-RING | KOBID 17.80 ± 0.21 x OD 22mm |
| 207. | YN30V00101S207 | [1] | GUARD | SMCover Superseded by part number: YN30V00101S094 |
| 264. | ZD12G04000 | [10] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 266. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 278. | ZS23C08035 | [5] | SCREW,Hex Socket Head, M8 x 35mm | KOBM08x1.25x35mm |
| 517. | YN30V00101S517 | [1] | HYDRAULIC VALVE | SMPoppet |
| 518. | YN30V00101S518 | [1] | HYDRAULIC VALVE | SMPoppet |
| 527. | YN30V00101S527 | [1] | SPRING | SM |
| 528. | YN30V00101S528 | [1] | SPRING | SM |
| 973. | ZS23C14160 | [8] | SCREW,Hex Socket Head, M14 x 160mm | KOBScrew -- M14x2.0x160mm |
| 974. | ZS23C14140 | [2] | SCREW,Hex Socket Head, M14 x 140mm | KOBM14x2.0x140mm |
