| . . | YN30V00101F1 | [1] | VALVE, CONTROL | KOBAssembly Superseded by part number: YN30V00101F6 |
| . . | YN30V00101F2 | [1] | CONTROL VALVE | KOBAssembly Superseded by part number: YN30V00101F6 |
| . . | YN30V00101F3 | [1] | CONTROL VALVE | KOBControl Valve Assembly Superseded by part number: YN30V00101F6 |
| 6. | NA | [5] | NOT SERVICED | FORPlug |
| 7. | ZD12P03800 | [7] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 8. | ZD12G03000 | [15] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 9. | ZD12P01500 | [11] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 10. | ZD12P02400 | [19] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 12. | YN30V00101S201 | [5] | GUARD | SM |
| 14. | YN30V00101S203 | [1] | GUARD | SM |
| 15. | YN30V00101S204 | [1] | GUARD | SM |
| 16. | YN30V00001S205 | [7] | COVER | KOB |
| 17. | YN30V00101S206 | [1] | GUARD | SM |
| 19. | YN30V00101S209 | [1] | GUARD | SM |
| 20. | YN30V00119F1 | [2] | VALVE | KOBAssembly, Lock |
| 23. | YN30V00101S216 | [1] | PISTON | SM |
| 24. | ZD12G05000 | [12] | O-RING,49.40mm ID x 55.60mm OD x 3.10mm | KOBID 49.40 ± 0.45 x OD 55mm |
| 25. | ZD12G04000 | [10] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 26. | ZD12P00700 | [4] | O-RING,1.6mm Thk x 6.8mm ID, 90 Duro | KOBO-Ring -- ID 06.80 ± 0.16 x OD 10mm |
| 31. | YN30V00101S301 | [1] | SPOOL | SMAssembly Superseded by part number: YN30V00101R220 |
| 32. | YN30V00101S302 | [1] | SPOOL | KOBSpool |
| 33. | YN30V00101S303 | [1] | SPOOL | SM Superseded by part number: YN30V00101R120 |
| 34. | YN30V00101S304 | [1] | SPOOL | KOBSpool Superseded by part number: YN30V00101R130 |
| 42. | YN30V00079S321 | [5] | SPRING | KOB |
| 43. | YN30V00079S322 | [4] | SPRING | KOB |
| 51. | 2436U1443S332 | [24] | SPRING SEAT | KOB |
| 52. | 2436U1165S336 | [12] | BOLT | KOB |
| 53. | 2436U1165S335 | [10] | STOP | KOB |
| 56. | YN30V00101S341 | [11] | HYDRAULIC VALVE | SM |
| 58. | YN30V00101S514 | [2] | HYDRAULIC VALVE | SM |
| 62. | 2436U1165S521 | [11] | SPRING | KOB |
| 64. | YN30V00089S523 | [1] | SPRING | KOB |
| 65. | YN30V00001S524 | [2] | SPRING | KOB |
| 68. | YN30V00001S551 | [13] | PLUG | KOB |
| 70. | YN30V00001S556 | [3] | PLUG | KOB |
| 73. | YN22V00002F1 | [2] | VALVE | KOBSee Figure 8.044 (03) |
| 74. | YN22V00002F9 | [3] | VALVE | KOBSee Figure 8.044 (03) |
| 76. | YN22V00029F1 | [1] | VALVE | KOBSee Figure 8.044 (04) |
| K. | YN30V00101R100 | [1] | REPAIR KIT | KOBContains Items (31, 42, 43, 51, 52 & 53) (F1, F3 Only) Superseded by part number: YN30V00101R220 |
| K. | YN30V00116R110 | [1] | REPAIR KIT | SMContains Items (32, 42, 43, 51, 52 & 53) |
| K. | YN30V00101R120 | [1] | REPAIR KIT | KOBContains Items (33, 42, 43, 51, 52 & 53) |
| K. | YN30V00116R130 | [1] | REPAIR KIT | SMContains Items (34, 42, 43, 51, 52 & 53) |
| K. | YN30V00101R140 | [1] | REPAIR KIT | KOBContains Items (35, 46, 47, 51, 52 & 54) |
| K. | YN30V00101R150 | [1] | REPAIR KIT | KOBContains Items (36,44, 45, 51, 52 & 53) |
| K. | YN30V00101R170 | [1] | REPAIR KIT | KOBContains Items (37, 48, 50, 51, 52 & 53) |
| K. | YN30V00116R170 | [1] | REPAIR KIT | SMContains Items (38, 42, 49, 51, 52 & 55) |
| K. | YN30V00101R190 | [1] | REPAIR KIT | KOBContains Items (39, 48, 50, 51, 52 & 53) |
| K. | YN30V00101R200 | [1] | REPAIR KIT | KOBContains Items (40, 48, 50, 51, 52 & 53) |
| K. | YN30V00101R210 | [1] | REPAIR KIT | KOBContains Items (41, 44, 45, 51, 52 & 53) (F1, F2 Only) |
| K. | YN30V00101R220 | [1] | SPOOL | KOBKit, Repair, Contains Items (42, 43, 51, 52, 53 & 83) |
