| . . | YN30V00101F1 | [1] | VALVE, CONTROL | KOBAssembly Superseded by part number: YN30V00101F6 |
| . . | YN30V00101F2 | [1] | CONTROL VALVE | KOBAssembly Superseded by part number: YN30V00101F6 |
| . . | YN30V00101F3 | [1] | CONTROL VALVE | KOBControl Valve Assembly Superseded by part number: YN30V00101F6 |
| 7. | ZD12P03800 | [7] | O-RING | KOBID 37.70 ± 0.37 x OD 44.7mm |
| 8. | ZD12G03000 | [15] | O-RING,29.40mm ID x 35.60mm OD x 3.10mm | KOBID 29.4 ± 0.29 x OD 35mm |
| 9. | ZD12P01500 | [11] | O-RING | KOBID 14.80 ± 0.20 x OD 19mm |
| 10. | ZD12P02400 | [19] | O-RING | KOBID 23.70 ± 0.24 x OD 30mm |
| 12. | YN30V00101S201 | [5] | GUARD | SM |
| 16. | YN30V00001S205 | [7] | COVER | KOB |
| 21. | YN30V00079S212 | [1] | PLATE | KOB |
| 22. | YN30V00101S213 | [1] | PLATE | KOB |
| 24. | ZD12G05000 | [12] | O-RING,49.40mm ID x 55.60mm OD x 3.10mm | KOBID 49.40 ± 0.45 x OD 55mm |
| 25. | ZD12G04000 | [10] | O-RING,39.40mm ID x 45.60mm OD x 3.10mm | KOBID 39.40 ± 0.37 x OD 45mm |
| 27. | ZS23C08025 | [40] | SCREW,Hex Socket Head, M8 x 25mm | KOBM08x1.25x25mm |
| 28. | ZS23C12025 | [4] | CAPSCREW,Hex Socket Head, M12 x 52mm | KOBSCREW M12x1.75x25mm |
| 29. | ZS23C12035 | [4] | SCREW,Hex Socket Head, M12 x 35mm | KOBM12x1.75x35mm |
| 38. | YN30V00101S308 | [1] | SPOOL | KOBAssembly Superseded by part number: YN30V00101R180 |
| 41. | YN30V00101S311 | [1] | SPOOL | SM Superseded by part number: YN30V00101R210 |
| 42. | YN30V00079S321 | [5] | SPRING | KOB |
| 44. | 2436U1165S371 | [3] | SPRING | KOB |
| 45. | 2436U1165S372 | [3] | SPRING | KOB |
| 49. | YN30V00101S328 | [1] | SPRING | SM |
| 51. | 2436U1443S332 | [24] | SPRING SEAT | KOB |
| 52. | 2436U1165S336 | [12] | BOLT | KOB |
| 53. | 2436U1165S335 | [10] | STOP | KOB |
| 55. | YN30V00101S340 | [1] | CLIP | SMSTOPPER |
| 56. | YN30V00101S341 | [11] | HYDRAULIC VALVE | SM |
| 59. | 2436U1231S513 | [1] | POPPET | KOB |
| 62. | 2436U1165S521 | [11] | SPRING | KOB |
| 68. | YN30V00001S551 | [13] | PLUG | KOB |
| 75. | YN30V01062P1 | [2] | PLUG | SMAssembly |
| K. | YN30V00101R100 | [1] | REPAIR KIT | KOBContains Items (31, 42, 43, 51, 52 & 53) (F1, F3 Only) Superseded by part number: YN30V00101R220 |
| K. | YN30V00116R110 | [1] | REPAIR KIT | SMContains Items (32, 42, 43, 51, 52 & 53) |
| K. | YN30V00101R120 | [1] | REPAIR KIT | KOBContains Items (33, 42, 43, 51, 52 & 53) |
| K. | YN30V00116R130 | [1] | REPAIR KIT | SMContains Items (34, 42, 43, 51, 52 & 53) |
| K. | YN30V00101R140 | [1] | REPAIR KIT | KOBContains Items (35, 46, 47, 51, 52 & 54) |
| K. | YN30V00101R150 | [1] | REPAIR KIT | KOBContains Items (36,44, 45, 51, 52 & 53) |
| K. | YN30V00101R170 | [1] | REPAIR KIT | KOBContains Items (37, 48, 50, 51, 52 & 53) |
| K. | YN30V00116R170 | [1] | REPAIR KIT | SMContains Items (38, 42, 49, 51, 52 & 55) |
| K. | YN30V00101R190 | [1] | REPAIR KIT | KOBContains Items (39, 48, 50, 51, 52 & 53) |
| K. | YN30V00101R200 | [1] | REPAIR KIT | KOBContains Items (40, 48, 50, 51, 52 & 53) |
| K. | YN30V00101R210 | [1] | REPAIR KIT | KOBContains Items (41, 44, 45, 51, 52 & 53) (F1, F2 Only) |
| K. | YN30V00101R220 | [1] | SPOOL | KOBKit, Repair, Contains Items (42, 43, 51, 52, 53 & 83) |
