纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-009[00]) - RADIATOR ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
760 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| . . | YN05P00062F1 | [1] | RADIATOR | SMAssembly, Incls. Refs. 1 - 28 Superseded by part number: YN05P00062F6 |
| 1. | YN05P00062S001 | [1] | RADIATOR | SM Superseded by part number: YN05P00062S039, LC05P01763P1 |
| 2. | YN05P00010S006 | [1] | RADIATOR CAP | KOBRadiator Superseded by part number: YN05P00088S032 |
| 3. | 2452U221S18 | [1] | DRAINCOCK/TAP SUPPLY | KOB |
| 4. | 2452U416S6 | [1] | HOSE | KOB |
| 5. | YB05P00001S022 | [2] | INSULATING PANEL | KOB |
| 6. | YN05P00058S002 | [1] | OIL COOLER | SMCOOLER, OIL Superseded by part number: YN05P00058R101 |
| 7. | YN05P00058S019 | [4] | INSULATOR | SM |
| 8. | YN05P00058S023 | [1] | INSULATOR | SM |
| 9. | YN05P00058S003 | [1] | COOLER | SMCOOLER, AIR |
| 10. | YN05P00058S022 | [1] | INSULATOR | SM |
| 11. | YN05P00062S029 | [1] | SUPPORT | SM |
| 12. | YN05P00062S012 | [2] | INSULATOR | SM |
| 13. | YN05P00062S013 | [2] | INSULATOR | SM |
| 14. | YN05P00062S014 | [1] | INSULATOR | SM |
| 15. | YN05P00062S015 | [1] | GUARD | SMSHROUD |
| 16. | YN05P00062S016 | [2] | RUBBER SEAL | SMRUBBER |
| 17. | YN05P00058S005 | [1] | GUARD | SM |
| 18. | YN05P00062S018 | [1] | GUARD | SM |
| 19. | GB05P00001S006 | [1] | HOSE,25.4mm ID x 2000mm L | KOB |
| 20. | 2452U267S8 | [2] | CLIP | KOB |
| 21. | YN05P00058S012 | [4] | COLLAR | SM |
| 22. | YN05P00058S013 | [4] | SEAT CUSHION | SMMOUNT, RUBBER |
| 23. | YN05P00058S014 | [4] | SEAT CUSHION | KOBMOUNT, RUBBER |
| 24. | ZM22C10030 | [4] | BOLT | KOBM10x1.50x30mm (Incls. Washer & Lockwasher) |
| 25. | 2452U377S6 | [4] | CAP | KOBScrew -- M06x1.0x112mm |
| 26. | 2452U202S5 | [4] | BOLT | KOBM06x1.0 |
| 27. | YN05P00062S027 | [1] | GUARD | SM |
| 28. | PY05P00002S009 | [13] | BOLT | KOB Superseded by part number: ZM12C08020 |
| . . | YN05P00058S032 | [2] | GASKET | SMNot Shown |
