纽荷兰零件查询(E215B) - CRAWLER EXCAVATOR - TIER 3 (ROPS CAB) ASN NBDA21800 (6/13-) (01-010[01]) - AIR CLEANER ASSY New Holland Constructuion
广数供应链运营团队, 15 02月, 2025，浏览：
384 次
| Pos. | Part No | Qty | Parts name | Comments |
|---|
| 1. | YN11P00033F1 | [1] | AIR FILTER | SMAir Cleaner Assy, Includes Ref. 1A-1L |
| 1A. | YR11P00008S005 | [1] | INDICATOR | KOB Superseded by part number: LV11P01017F1 |
| 1B. | LQ11P00023S002 | [1] | AIR FILTER | KOB Superseded by part number: 87564846 |
| 1C. | GG11P00008S002 | [1] | AIR FILTER | KOB Superseded by part number: 87564844 |
| 1D. | EB11P00001S008 | [1] | LABEL | KOB |
| 1E. | NSS | [1] | NOT SERVICED SEPARATELY | CON |
| 1F. | YN11P00029S006 | [1] | O-RING | KOB |
| 1G. | EB11P00001S006 | [1] | ADAPTER | KOB |
| 1L. | YW11P00004S004 | [1] | VALVE | KOB |
| 7. | ZS18C10025 | [12] | SCREW,Hex, M10 x 25mm | KOBM10x1.50x25mm |
| 16. | ZW16P10000 | [12] | WASHER | KOBID 10.5 x OD 21 x Th 2.0mm |
